TD Series

2kW ⁄ 3kW ⁄ 4kW ⁄ 6kW
T6016D / T6022D / T10025D / T6033D / T12033D / T12035D

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

Modular Design

Han's tube laser series uses mix and match modular loading and unloading structure. This modular combination brings users munch more flexibility to fit their own needs.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

Horizontal Welding Bed

● The machine adopts horizontal structure, high-precision gear rack and high-precision linear guide rail, with stable transmission and high accuracy. It is equipped with blanking device, which improves the production efficiency of the machine tool.

● The lathe bed is made of welded structure, ungoes rough machining after annealing, vibration aging treatment, and finish machining, which can completely eliminate the stress of welding and processing. It has good rigidity, high precision, and can be used for a long time without deformation.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

"Negative Pressure Dedusting" in the Pipe

The pipe interior and cutting area adopt negative pressure suction dust removal, which has good dust removal effect and is clean and environmentally friendly.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser T6016D

Pneumatic chuck

Pneumatic clamping with four claw roller, and self-centering function is realized by grasping and clamping linkage. The feeding chuck seat and fixed chuck seat are of plate welding structure. After high temperature annealing, rough machining, vibration aging and high-precision machining, the chuck has good rigidity, light weight and good dynamic performance.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

Han's Cutting Head

● The cutting head adopts capacitive sensor, which has high sensing accuracy, sensitive response, stable and reliable performance.

● X,Y,Z linear axis and A, B rotary axis all adopt high resolution high-precision large torque servo motor, which has high precision, high speed, large torque, large inertia, stable and durable performance, ensuring the high speed and acceleration of the whole machine.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

Laser Source

The fiber laser independently developed by Han's Laser has the advantages of large heat dissipation area, good beam quality, small size, etc. Compared with the gas laser and solid laser, it has obvious advantages, and has gradually developed into an important candidate in high.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser TD Series

Professional nesting software

● Provide a series of cutting modules, including intersecting line cutting, various groove, hole
and pattern cutting, and various angle cutting, which are simple and practical and what you
see is what you get.
● Output CAM files and CNC cutting programs for cutting round tubes and various square tubes.
● Support multiple types of numerical control laser cutting machines with multiple axes.
● Support Windows 98/2000/NT/Vista operating system and Chinese and English operating
interface.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser

Technical data

TD Series

Machine Type

Laser Source Power

Max. Machining Range

Cutting Speed

Max. Weight of Single Tube

Unload Tube Length(Custom)

Positioning Speed

Max. Material Length For Loading

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser

TD Series

2000w ⁄ 3000w ⁄ 4000w ⁄ 6000w (optional)

φ15-220 mm □15-150mm φ15-254 mm □15-200mm φ11-330 mm □10-230mm

100rpm

100kg/150kg/200kg

0-2000mm

100m/min

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser CONFIGURATION

Automation device

Semi Automatic Feeding(Optional)

The semi automatic feeding module can be installed on the front of the machine, which makes it easy to put pipes on shelves in batches and greatly reduces the preparation time of raw materials.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser

Fully Automatic(Optional)

The fully automatic feeding module can be installed on the back of the machine, and the raw material stacking rack can automatically provide pipes, thus significantly improving the loading speed and production efficiency.
