SLU Series

Single Loading & Unloading System

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Single Loading & Unloading System

The SLU-Series automated loading and unloading system is composed of automated loading and unloading control system, automated loading and unloading device, plane cutting machine and its CNC system, raw material cart and sorting cart.It features the characteristics of high efficiency, low cost and convenient operation.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Main Parts

The automated loading and unloading system is mainly composed of C-shaped bracket assembly line, loading and unloading integrated device, high and low electronic carts and control system.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

C-shaped Bracket Assembly Line

The main machining parts such as the span beam of the C-shaped bracket are welded by profiles. The process is as follows: Welding → Rough machining → Vibratory stress relief → Refined machining, which can better relieve the stress caused by welding and processing and improve the stability of the C-shaped bracket assembly line.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Integrated loading and unloading

The loading and unloading integrated mechanism is mainly composed of a main structural frame, a suction cup, a material fork mechanism, a transmission mechanism and other sensing elements.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Effective Layering

Sensitive thickness measurement, precise layering, ensuring single sheet production and preventing incorrect cutting of plates during the production process.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Seamless Transition

Continuous loading and unloading significantly boost productivity by eliminating unexpected manual operations.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Raw material and sorting truck combination

The automated assembly line is equipped with one group of RGV electronic cart platform, and the higher one is used as sorting cart for sorting and transportation of cut workpiece and wastes; the lower one is used as raw material cart for raw material storage. The cart platform can bear 4T load for a long time.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser SLU Series

Safety Fence

Equipped with safety interlock switches, the equipment operates automatically in the area, and adopts safety guardrails without dead angle protection to prevent personnel from entering and ensure the safe operation of the system.

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser
Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser

Technical data

SLU-Series

Machine Type

Floor space (L×W×H)

Maximum horizontal traveling speed of the loading and unloading device

Maximum up and down positioning speed of the loading and unloading device

Maximum size of loaded sheet

Maximum size of unloaded sheet

Control system

Maximum attraction weight

Number of electronic cart

Bearing of electronic cart

Horizontal traveling speed of electronic cart

Rated power voltage

Frequency

Phase

Laser Cutting, Welding, Bending, Automation Solution Provider | Han's Laser

SLU-Series

18.5 m×5.6 m×4 m

40 m/min

8 m/min

3000×1500×5

3000×1500×5

PLC control system

180 kg

2

4t

20m/min

380 V

50 Hz

3
